Beschreibung
| Rated current | : 350mA |
| Rated power | : 70W |
| Ripple & noise (max.) | : 5% |
| Current adjustment range | : 210-350mA |
| Input | |
|
Voltage range |
: 90~305VAC / 127~431VDC |
| Frequency range | : 47~63Hz |
| Power factor | : PF>0,98/115VAC, PF>0,95/230VAC, PF>0,93/277VAC at full load |
| Effency | : 91% |
| AC current | : 0,88A/115VAC, 0,45A/230VAC, 0,38A/277VAC |
|
: |
|
| Protection | |
| Over voltage |
: 300-340V |
| Over temperature | : 85°C +-10°C (RTH2) Protection type: Shut down o/p, re-power on the recover |
| Enviroment | |
| Working temperature | : -40°C – +70°C |
| Mechanic | |
| Dimension | : L196 W62 39mm |
| Weight | : 0,84kg |
