Name: MEANWELL LED-Schaltnetzteil HLG-60H-42AB 42VDC/1,45A
SKU: cdkkfqxq09776
Availability: InStock

Beschreibung

Output
DC voltage	: 42V
Rated current	: 1,45A
Rated power	: 60W
Ripple & noise (max.)	: 150mVpp
Voltage adjustment range	: 40~46V
Input
Voltage range	: 90~305VAC / 127~431VDC
Frequency range	: 47~63Hz
Power factor	: PF>0,98/115VAC, PF>0,95/230VAC, PF>0,92/277VAC at full load
Effency	: 87,5%
AC current	: 0,64/115VAC, 0,32A/230VAC, 0,30A/277VAC
AC inrush current (230VAC)	: Cold start 70A
Protection
Over current	: 95~108% Protection type: Constant current limiting, recovers automatically after fault condition is removed
Short circuit	: Hiccup mode, recovers automatically after fault condition is removed
Over voltage	: 48~58V Protection type: Shut down o/p, re-power on the recover
Over temperature	: 85°C +-10°C (RTH2) Protection type: Shut down o/p, re-power on the recover
Enviroment
Working temperature	: -40°C – +70°C
Mechanic
Dimension	: L171 W61,5 38,8mm
Weight	: 0,73kg

Please note	: HLG-60H-42- Blank : IP67rated. Cable for I/O conncetion. A : IP65 rated. Outpult voltage and constant current level can be adjusted through internal poti. B : IP67 rated. Constant current level adjustable through output cable with 1~10VDC or 10V PWM signal or resistance. D : IP67 rated. Timer dimming function. AB : Io and Vo adujstable through built-in poetntiometer & 3 in 1 dimming function (1-10Vdc,10V PWM signal and resistance
