Digiplus DL 514 BH

Beschreibung

digital ultrasonic unit with power control
dimensions:

• Inner tank dimensions l×w×d: 325×300×200mm
• Exterior dimensions l×w×h: 355×325×385mm
• Weight kg: net 14,7; gross 17,7
• Capacity: 18,7 litres
• Filling volume for cleaning: 12,5 litres

proposal for application:

• electrode
• jewels, ornaments
• coins, medals
• laboratory
• dental line
• medical line
• workshop

features:

• control elements: push button
• Power settings: 20 – 100 %
• DEGAS – rapid degassing
• Built-in heater 20 – 80 °C, 600 W, thermostatically adjustable
• Tank: stainless steel AISI 304
• Housing: stainless steel AISI 304
• outlet: ball valve G 1/4
• protected against spray
• Protection grade: IP 33
• Timer: 1, 2, 3, 4, 5, 10, 15, 30 min and infinite

Technical data:

• Transducer: 4 PZT large area transducer
• HF generator: overload protected, constant power
• Operating mode: double half-wave
• Frequency: 35 kHz, automatic frequency control
• Ultrasonic peak output: 1200 W*

(in combination with SweepTec a four times higher value of HF-output is obtained)

• HF power: 300 W eff
• Current consumption:230V – 3,6 A; 115V – 7,1 A
• Mains connection: Standard 230 V~ 50/60 Hz, alternative 115 V~ 50/60 Hz
• Leakage current: < 0,5 mA
• Fixed power cable, 2 m
